IPR-系列@滾架式壓床
The Enerpac roll frame press has a 容量 of 50 to 200 tons
Quality welded frame for maximum strength and long life
Frame rolls easily on four steel roller bearings
Hydraulic clamp cylinders lock frame into position
Exclusive “Hydra-Lift?” bolster for effortless adjustment of the vertical daylight
Standard roller head design allows movement of the cylinder from side to side
All roll frame press models in the Quick Selection Chart have been matched to a pump, cylinder, hoses and gauge, offering the complete package
Roll Frame design features a stationary bed with the ability to support heavy loads
| Press Capacity |
Vertical Daylight |
Max. Bed Width | Electric Pump |
Model Number |
Double-acting Cylinder | Speed | Weight | |||
|---|---|---|---|---|---|---|---|---|---|---|
| inch/sec | ||||||||||
| inch |
Model Number |
stroke |
Model Number |
Rapid Advance |
Pressing | pound | ||||
| ton | min | max. | inch | inch | ||||||
| 50 | 6.00 | 37.12 | 28.75 | ZE4420SB-N | IPR-5075 | 13.13 | RR-5013 | 1.0 | 11.1 | 1,961 |
| 100 | 6.28 | 41.28 | 35.00 | ZE5420SG-N | IPR-10075 | 13.13 | RR-10013 | 1.5 | 10.3 | 3,849 |
| 200 | 11.00 | 51.00 | 48.00 | ZE5420SG-N | IPR-20075 | 13.00 | RR-20013 | 3.1 | 22.1 | 7,869 |
