ZW-系列@電動工裝夾具泵
Enerpac Z-Class high efficiency single-stage electric workholding pumps
Pallet coupling pumps
Provides momentary 壓力 and 流量 to fixture
Ideal for pallet disconnect systems
Continuous connection pumps
Provides solenoid control of one single- or double-acting circuit
Includes pilot operated check valve ensuring 壓力 is maintained in circuit
Single station DO3 pumps
Industry standard mounting for manual or electric valves
Options: backlit LCD, heat exchanger, 壓力 transducer, level & temperature switches and roll bars
SAE Ported for Remote Valves
Z系列泵效率高，流量更大，旁路壓力高，散熱性能好，工作電流較同類產品低18%
全封閉式帶風冷散熱裝置電動機，延長泵的使用壽命及適應苛刻的工作環境
閥的種類和油箱規格可以提供特殊的形式以滿足更多要求的工裝夾具的應用
高強度的模塑電控箱保護電路，電機及數顯裝置，使泵避免冷卻液和污染物帶來的危害
|
Output Flow at 5000 psi in3/min |
Motor |
Motor Voltage Volt-phase at 60Hz |
Usable Oil Capacity gal |
Pallet Coupling Pumps Model Number |
Continuous Connection Pumps Model Number |
Single Station DO3 Pumps Model Number |
SAE Ported for Remote Valving Model Number |
Weight lbs |
|---|---|---|---|---|---|---|---|---|
| 40 | 1.0 | 115-1 | 2 | ZW3408DB-FT | ZW3408FB-FT | ZW3008GB-11 | ZW3008HB-FT01 | 115 |
| 40 | 1.0 | 115-1 | 2.5 | ZW3410DB-FT | ZW3410FB-FT | ZW3010GB-11 | ZW3010HB-FT01 | 134 |
| 40 | 1.0 | 230-1 | 2 | ZW3408DI-FT | ZW3408FI-FT | ZW3008GI-11 | ZW3008HI-FT01 | 115 |
| 40 | 1.0 | 230-1 | 2.5 | ZW3410DI-FT | ZW3410FI-FT | ZW3010GI-11 | ZW3010HI-FT01 | 134 |
| 60 | 1.0 | 115-1 | 2.5 | ZW4410DB-FT | ZW4410FB-FT | ZW4010GB-11 | ZW4010HB-FT01 | 120 |
| 60 | 1.0 | 230-3 | 2.5 | ZW4410DG-FT | ZW4410FG-FT | ZW4010GG-11 | ZW4010HG-FT01 | 120 |
| 60 | 1.0 | 460-3 | 2.5 | ZW4410DJ-FT | ZW4410FJ-FT | ZW4010GJ-11 | ZW4010HJ-FT01 | 120 |
| 120 | 1.5 | 115-1 | 2.5 | ZW5410DB-FT | ZW5410FB-FT | ZW5010GB-11 | ZW5010HB-FT01 | 130 |
| 120 | 1.5 | 230-3 | 2.5 | ZW5410DG-FT | ZW5410FG-FT | ZW5010GG-11 | ZW5010HG-FT01 | 130 |
| 120 | 1.5 | 460-3 | 2.5 | ZW5410DJ-FT | ZW5410FJ-FT | ZW5010GJ-11 | ZW5410HJ-FT01 | 130 |
