FN, MF, BS-系列@油缸
應用于最適宜的安裝和夾具適用性可適合各種應用場合
安裝法蘭
用于擰緊油缸以適合應用
法蘭螺母
用于在任意位置安裝螺紋缸體或油缸
接觸螺釘
在您的夾緊應用中可允許油缸工作為一個數據點，并在油缸用于推進場合時保護活塞
|
Mounting Thread inch |
Flange Nut Model Nr. |
Mounting Flange Model Nr. |
Spherical Contact Bolt Model Nr. |
Yoke Model Nr. |
Mounting Bracket Cylindrical Model Nr. |
Mounting Bracket Rectangular Model Nr. |
|---|---|---|---|---|---|---|
| #6-32 UNC | – | – | BS-21 | – | – | – |
| #8-32 UNC | – | – | BS-41 | – | – | – |
| .250-28 UNF | – | – | BS-61 | – | – | – |
| .313-24 UNF | – | – | BS-81 | Y-3121 | – | – |
| .375-16 UNC | – | – | BS-91 | – | – | – |
| .500-13 UNC | – | – | BS-101 | – | – | – |
| .500-20 UNF | FN-121 | MF-121 | – | – | – | – |
| .750-16 UNF | FN-201 | MF-201 | – | – | – | – |
| 1.000-12 UNF | FN-251 | MF-251 | – | – | – | – |
| 1.125-16 UN | FN-281 | MF-281 | – | – | – | – |
| 1.250-16 UN | FN-301 | – | – | – | – | – |
| 1.313-16 UN | FN-331 | MF-331 | – | – | ||
| 1.375-18 UNEF | FN-351 | MF-351 | – | AW-5 | ||
| 1.500-16 UN | – | – | – | – | AW-53 | AW-51 |
| 1.625-16 UN | FN-421 | MF-421 | – | – | – | – |
| 1.875-16 UN | FN-481 | MF-481 | – | – | – | AW-89 |
| 2.125-16 UN | FN-551 | MF-551 | – | – | – | – |
| 2.250-14 UN | – | – | – | – | – | AW-102 |
| 2.500-16 UN | FN-651 | MF-651 | – | AW-19 | ||
| 2.750-16 UN | – | – | – | – | AW-121 | – |
| 3.125-16 UN | FN-801 | MF-801 | – | – | – | AW-90 |
