WS-系列@彈簧前進支撐油缸
當工件安裝在夾具內時彈簧前進支撐油缸接觸工件
低壓鎖緊能力可使用機床液壓系統
強大的支撐能力允許更緊湊夾具設計
耐腐材料的應用可適應各種冷卻液和環境
螺紋式和油路塊式氣孔設計可防止在夾具上安裝后冷卻液進入系統
變形最小化提高了加工精度
多種安裝形式增加了設計適用性
去掉彈簧并向排氣口供氣壓可以被用作氣動前進油缸
| Max. Support Force | Support Plunger Stroke | Manifold Mount | Threaded Body | Lower Flange | Cartridge Style | Plunger Contact Spring Force |
Oil Capa- city |
Max. Oil Flow | |
|---|---|---|---|---|---|---|---|---|---|
| pound | inch | pound | inch3 | in3/min | |||||
| ext. | retr. | ||||||||
| 1650 | 0.38 | WSM-71 | - | - | - | 2.0 | 5.8 | 0.04 | 40 |
| 1650 | 0.38 | – | WST-71 | – | – | 2.0 | 5.8 | 0.04 | 40 |
| 2500 | 0.38 | – | – | WSL-111 | – | 3.4 | 5.2 | 0.06 | 60 |
| 5000 | 0.38 | – | – | WSL-221 | – | 2.1 | 19.5 | 0.19 | 190 |
| 7500 | 0.54 | – | – | WSL-331 | – | 4.0 | 17.5 | 0.24 | 240 |
| 10,000 | 0.66 | – | – | WSL-441* | – | 3.3 | 22.0 | 0.30 | 300 |
| 1650 | 0.38 | – | – | – | WSC-72 | 2.0 | 5.8 | 0.04 | 40 |
| 2500 | 0.38 | – | – | – | WSC-112 | 3.4 | 5.2 | 0.06 | 60 |
| 5000 | 0.47 | – | – | – | WSC-222 | 2.1 | 19.5 | 0.19 | 190 |
* This product is made to order, contact Enerpac for delivery information before specifying in your design.
