WF-系列@液壓前進支撐油缸
可以毫無阻礙地拆裝工件
活塞保持縮回狀態到油壓達到適用要求，可以毫無阻礙的拆裝工件
低壓鎖緊能力可使用與機床液壓系統
強大的支撐能力允許更緊湊夾具設計
耐腐材料的應用可適應各種冷卻液和環境
紋式和油路塊氣孔設計可在安裝在夾具上后防止冷卻液和切屑進入機構
變形最小化提高了加工精度
種安裝形式增加了設計適應性
| Max. Support Force | Support Plunger Stroke | Manifold Mount | Threaded Body | Lower Flange | Cartridge Style | Plunger Contact Spring Force |
Oil Capa- city |
Max. Oil Flow | |
|---|---|---|---|---|---|---|---|---|---|
| pound | inch | pound | inch3 | in3/min | |||||
| ext. | retr. | ||||||||
| 1650 | 0.39 | WFM-71 | - | - | - | 2.0 | 5.8 | 0.04 | 40 |
| 1650 | 0.40 | – | WFT-71 | – | – | 2.0 | 5.8 | 0.04 | 40 |
| 2500 | 0.40 | – | – | WFL-111 | – | 3.4 | 5.2 | 0.06 | 60 |
| 5000 | 0.41 | – | – | WFL-221 | – | 2.1 | 19.5 | 0.19 | 190 |
| 7500 | 0.53 | – | – | WFL-331 | – | 4.0 | 17.5 | 0.24 | 240 |
| 10,000 | 0.65 | – | – | WFL-441* | – | 3.3 | 22.0 | 0.30 | 300 |
| 1650 | 0.39 | – | – | – | WFC-72 | 2.0 | 5.8 | 0.04 | 40 |
| 2500 | 0.36 | – | – | – | WFC-112 | 3.4 | 5.2 | 0.06 | 60 |
| 5000 | 0.41 | – | – | – | WFC-222 | 2.1 | 19.5 | 0.19 | 190 |
* This product is made to order, contact Enerpac for delivery information before specifying in your design.
