ECH, ECM-系列@下壓式夾鉗
低外形的夾鉗，用于無障礙上表面的加工
獨立的水平和垂直運動實現真正的下壓效果
緊湊型尺寸和低高度外形相比專門的虎鉗具有更大的柔性和安裝經濟性
油路塊和BSPP兩種接口方
由高合金鑄件，熱處理后的夾鉗和活塞桿組成
防污染設計，維護成本低，可移動式保護罩用于碎屑清除
兩側的油孔便于安裝
對大型工件可選用機械式夾鉗來提供下壓力
包含在內的安裝螺栓使固定更容易
|
Lateral Clamping Force at 5,000 psi |
Pull Down Force at 5,000 psi |
Stroke |
Model Number |
Effective Area |
Oil Capacity |
Mounting Bolts * included |
Mechanical Counter Holds ** |
|---|---|---|---|---|---|---|---|
| pound | pound | inch | inch2 | inch3 | mm | ||
| 870 | 290 | .20 | ECH-52 | .18 | .03 | M8 x 45 | ECM-5 |
| 3900 | 1300 | .31 | ECH-202 | .78 | .24 | M12 x 80 | ECM-20 |
* Torque M8 with 18 Ft.lbs (25 Nm), M12 with 63 Ft.lbs (85 Nm). The use of T-nuts requires longer bolts.
** Mechanical counter holds are sold separately.
