GT-系列@液壓螺栓拉伸器
六種施力頭，尺寸從5/8" 到33/4"或者從M16到M95
雙油口，可快速連接多個工具
每種尺寸的動力單元只配有一種規(guī)格的支承橋
可拆卸并旋轉(zhuǎn)的支承橋簡化了工具定位工作
完整的支承橋窗口
行程指示器
表面經(jīng)過特別處理，可防治銹蝕
防滑把手確保穩(wěn)妥操作
通用型和多用途工具
|
Load Cell and Bridge Reference |
Bolt Range | Cylinder Effective Area | Load Capacity at 21,750 psi | Stroke | Weight | |
|---|---|---|---|---|---|---|
| (inch) | (mm) | (in2) | (ton) | (in) | (lbs) | |
| GT1-LCB | ? -1 | M16-M30 | 2.32 | 25.2 | 0.39 | 6.60 |
| GT2-LCB | 1? -1? | M30-M39 | 4.15 | 45.1 | 0.39 | 9.02 |
| GT3-LCB | 1? -2 | M39-M52 | 7.95 | 86.4 | 0.39 | 15.4 |
| GT4-LCB | 2 -2? | M52-M68 | 15.16 | 164.9 | 0.39 | 26.84 |
| GT5-LCB | 2? -3? | M68-M80 | 23.37 | 254.1 | 0.39 | 41.14 |
| GT6-LCB | 3? - 3? | M80-M95 | 29.41 | 319.8 | 0.39 | 61.16 |
|
Load Cell and Bridge Reference |
Thread Size | Adaptor Kit Model Number | Pitch Between Bolts | Minimum Height | Weight |
|---|---|---|---|---|---|
| (in) | (in) | (lbs) | |||
| GT1-LCB | M16 x 2 | GT1PM-NRS01620 | 2.17 | 6.65 | 3.48 |
| M18 x 2,5 | GT1PM-NRS01825 | 2.20 | 6.50 | 3.32 | |
| M20 x 2,5 | GT1PM-NRS02025 | 2.24 | 6.50 | 3.15 | |
| M24 x 3 | GT1PM-NRS02430 | 2.32 | 6.46 | 2.88 | |
| M27 x 3 | GT1PM-NRS02730 | 2.44 | 6.57 | 2.55 | |
| M30 x 3,5 | GT1PM-NRS03035 | 2.56 | 6.69 | 2.22 | |
| 5/8" 11un | GT1P-NRS0625U11 | 2.17 | 6.65 | 3.45 | |
| ?" 10un | GT1P-NRS0750U10 | 2.20 | 6.50 | 3.17 | |
| 7/8" 9un | GT1P-NRS0875U09 | 2.32 | 6.46 | 2.86 | |
| 1" 8un | GT1P-NRS1000U08 | 2.44 | 6.57 | 2.68 | |
| 11/8" 8un | GT1P-NRS1125U08 | 2.56 | 6.69 | 2.31 | |
| GT2-LCB | M30 x 3,5 | GT2PM-NRS03035 | 2.80 | 6.81 | 5.68 |
| M33 x 3,5 | GT2PM-NRS03335 | 2.91 | 6.85 | 5.21 | |
| M36 x 4 | GT2PM-NRS03640 | 3.03 | 6.97 | 4.77 | |
| M39 x 4 | GT2PM-NRS03940 | 3.15 | 7.09 | 4.25 | |
| 11/8" 8un | GT2P-NRS1125U08 | 2.80 | 6.81 | 5.81 | |
| 1?" 8un | GT2P-NRS1250U08 | 2.91 | 6.85 | 5.32 | |
| 13/8" 8un | GT2P-NRS1375U08 | 3.03 | 6.97 | 4.84 | |
| 1?" 8un | GT2P-NRS1500U08 | 3.15 | 7.09 | 4.29 | |
| GT3-LCB | M39 x 4 | GT3PM-NRS03940 | 3.62 | 8.35 | 12.50 |
| M42 x 4,5 | GT3PM-NRS04245 | 3.78 | 8.46 | 11.77 | |
| M45 x 4,5 | GT3PM-NRS04545 | 3.90 | 8.58 | 10.96 | |
| M48 x 5 | GT3PM-NRS04850 | 4.13 | 8.50 | 10.25 | |
| M52 x 5 | GT3PM-NRS05250 | 4.25 | 8.66 | 9.20 | |
| 1?" 8un | GT3P-NRS1500U08 | 3.62 | 8.35 | 12.56 | |
| 15/8" 8un | GT3P-NRS1625U08 | 3.78 | 8.46 | 11.70 | |
| 1?" 8un | GT3P-NRS1750U08 | 3.90 | 8.58 | 10.89 | |
| 17/8" 8un | GT3P-NRS1875U08 | 4.13 | 8.50 | 10.10 | |
| 2" 8un | GT3P-NRS2000U08 | 4.25 | 8.66 | 9.17 | |
| GT4-LCB | M52 x 5 | GT4PM-NRS05250 | 4.65 | 9.45 | 23.63 |
| M56 x 5,5 | GT4PM-NRS05655 | 4.76 | 9.61 | 22.22 | |
| M60 x 5,5 | GT4PM-NRS06055 | 4.88 | 9.76 | 20.77 | |
| M64 x 6 | GT4PM-NRS06460 | 5.00 | 9.92 | 19.32 | |
| M68 x 6 | GT4PM-NRS06860 | 5.12 | 10.08 | 17.80 | |
| 2" 8un | GT4P-NRS2000U08 | 4.65 | 9.45 | 23.63 | |
| 2?" 8un | GT4P-NRS2250U08 | 4.76 | 9.61 | 21.23 | |
| 2?" 8un | GT4P-NRS2500U08 | 5.00 | 9.92 | 18.63 | |
| GT5-LCB | M68 x 6 | GT5PM-NRS06860 | 5.71 | 10.94 | 38.02 |
| M72 x 6 | GT5PM-NRS07260 | 5.87 | 11.10 | 36.06 | |
| M76 x 6 | GT5PM-NRS07660 | 5.98 | 11.26 | 34.03 | |
| M80 x 6 | GT5PM-NRS08060 | 6.38 | 11.54 | 32.01 | |
| 2?" 8un | GT5P-NRS2500U08 | 5.67 | 10.79 | 39.16 | |
| 2?" 8un | GT5P-NRS2750U08 | 5.87 | 11.10 | 35.84 | |
| 3" 8un | GT5P-NRS3000U08 | 5.98 | 11.26 | 32.45 | |
| 3?" 8un | GT5P-NRS3250U08 | 6.38 | 11.54 | 28.86 | |
| GT6-LCB | M80 x 6 | GT6PM-NRS08060 | 6.65 | 12.28 | 49.02 |
| M85 x 6 | GT6PM-NRS08560 | 6.65 | 12.28 | 46.20 | |
| M90 x 6 | GT6PM-NRS09060 | 7.01 | 12.48 | 42.57 | |
| M95 x 6 | GT6PM-NRS09560 | 7.13 | 12.68 | 39.69 | |
| 3?" 8un | GT6P-NRS3250U08 | 6.65 | 12.28 | 45.56 | |
| 3?" 8un | GT6P-NRS3500U08 | 7.01 | 12.48 | 41.43 | |
| 3?" 8un | GT6P-NRS3750U08 | 7.13 | 12.68 | 36.94 |
