SU7-系列@7MPa轉角油缸
7MPa的工作壓力與低壓機床供油壓力相匹配
重復夾緊精度高
安裝法蘭特有BSPP及油路塊接口
可隨意選用左旋或右旋方式
標準長度壓板帶有螺紋孔，用以調整螺栓或加固墊塊
加長型壓板可根據客戶要求長度定制
新的開槽設計使用固定壓板所需扭矩更小
對于長度超過標準型的壓板，需要減少其工作壓力與夾緊力
|
夾緊ing Force at 70 bar kN |
Total Plunger 行程 mm |
夾緊ing 行程 mm |
Model Number * | Arm Rotation |
Single Acting |
Double Acting |
Cylinder Effective Area cm2 |
Cylinder Oil 容量 cm2 |
夾緊 Arms (sold separately) |
|
|---|---|---|---|---|---|---|---|---|---|---|
| Standard | Long | |||||||||
| 2 | 22.1 | 12 | SURS-722 | Right Hand | * | 3.02 | 6.7 |
|
|
|
| 3.5 | 22.1 | 12 | SURS-732 | Right Hand | * | 5.28 | 11.7 |
|
|
|
| 5 | 22.1 | 12 | SURS-752 | Right Hand | * | 7.54 | 16.7 |
|
|
|
| 7 | 22.1 | 12 | SURS-772 | Right Hand | * | 10.3 | 22.8 |
|
|
|
| 9 | 22.1 | 12 | SURS-792 | Right Hand | * | 13.19 | 29.1 |
|
|
|
| 20 | 22.1 | 12 | SURS-7202 | Right Hand | * | 30.44 | 67.3 |
|
|
|
| 2 | 22.1 | 12 | SURD-722 | Right Hand | * | 3.02 | 6.7 |
|
|
|
| 3.5 | 22.1 | 12 | SURD-732 | Right Hand | * | 5.28 | 11.7 |
|
|
|
| 5 | 22.1 | 12 | SURD-752 | Right Hand | * | 7.54 | 16.7 |
|
|
|
| 7 | 22.1 | 12 | SURD-772 | Right Hand | * | 10.3 | 22.8 |
|
|
|
| 9 | 22.1 | 12 | SURD-792 | Right Hand | * | 13.19 | 29.1 |
|
|
|
| 20 | 22.1 | 12 | SURD-7202 | Right Hand | * | 30.44 | 67.3 |
|
|
|
* Replace "R" with "L" for Left Hand models.
* Add "S" to the end of the model number for position sensing staff
