LW-系列@液壓提升器
最小安裝間隙10mm
700bar壓力時頂升力16ton
每一階梯都可以滿負荷承載
垂直頂升
獨一無二的聯鎖楔形設計
單作用、彈簧復位
包括安全墊塊SB-2
包括RC系列油缸和CR-400接頭
|
Maximum Lifting Force |
Lifting Stroke |
Model Number |
Tip Clearance/ Max. Spread* |
Maximum Operating Pressure |
Oil Capacity |
Weight |
|---|---|---|---|---|---|---|
| (ton) | (in) | (in) | (psi) | (in3) | (lbs) | |
| 16 | .83 | LW-16 | .39 / 2.72 | 10,000 | 4.75 | 15.4 |
For using two or four lifting wedges simultaneously use split-flow manifolds AM-21 or AM-41.
* Maximum spread 2.72 inches when using optional stepped block LWB-1.
