ZA4-系列@氣動液壓泵
秉承Z-系列泵效率高，流量大，旁邊壓力高的設計特點
雙速操作減少循環(huán)周期，提高工作率
兩個內置式溢流閥，一個是出場前設置好用于過載保護，另一個是用戶可調溢流閥用于預設系統(tǒng)最大壓力
所有尺寸的油箱都配有透明式液位計或液位指示器用于快速，方便的監(jiān)控油箱液位
閥和油箱的多種配置形式可應用于一些特殊場合
高的旁通壓力提高工作效率
選配的散熱器可以加熱廢氣防止凍結和降低油溫
|
Used with Cylinder |
Usable Oil Capacity |
Valve Model Number 2) |
Valve Function |
Model Number |
Output Flow Rate 1) | Weight | |||
|---|---|---|---|---|---|---|---|---|---|
| (in3/min at psi) | |||||||||
| (gal) | 100 | 700 | 5000 | 10,000 | (lbs) | ||||
|
Single- acting |
1.0 |
Manual VM32 |
Advance/ Retract |
ZA4204MX | 850 | 675 | 110 | 80 | 65.5 |
| 1.75 | ZA4208MX | 850 | 675 | 110 | 80 | 75.7 | |||
| 5.0 | ZA4220MX | 850 | 675 | 110 | 80 | 112.7 | |||
|
Double- acting |
1.0 |
Manual VM43 |
Advance/ Hold/ Retract |
ZA4404MX | 850 | 675 | 110 | 80 | 66.7 |
| 1.75 | ZA4408MX | 850 | 675 | 110 | 80 | 76.9 | |||
| 2.5 | ZA4410MX | 850 | 675 | 110 | 80 | 87.1 | |||
| 5.0 | ZA4420MX | 850 | 675 | 110 | 80 | 113.9 | |||
| 10.0 | ZA4440MX | 850 | 675 | 110 | 80 | 164.6 | |||
1) Actual flow will vary with air supply
2) See valve section for hydraulic symbols and details
