MP-系列@多介質手動泵
Enerpac multifluid hand pumps are ideal for testing and filling applications
無與倫比的抗腐蝕性能
泵體外殼面鍍鋁，泵體內各部件采用不銹鋼材料
標準的丁腈橡膠密封可用于多種介質，比如軟化水、油或水的乳狀液、乙二醇溶液、礦物油
可選的EPDM密封用于特種液壓油或制動液
雙速操作，最高壓力可達1000bar
外部可調溢流閥
1/4" NPTF gauge port.
|
Pump Type |
Pressure Rating |
Model Number |
Oil Displacement per Stroke |
Max. Handle Effort |
Piston Stroke |
Weight | ||
|---|---|---|---|---|---|---|---|---|
| psi | in3 | |||||||
| 1st stage | 2nd stage | 1st stage | 2nd stage | pound | in | lbs | ||
| Two-speed | 500 | 1500 | MP-110 | 3.2 | 1.28 | 99 | 1.04 | 14.5 |
| 500 | 5000 | MP-350 | 3.2 | .43 | 99 | 1.04 | 14.5 | |
| 500 | 10,000 | MP-700 | 3.2 | .18 | 99 | 1.04 | 14.5 | |
| 500 | 14,500 | MP-1000 | 3.2 | .12 | 99 | 1.04 | 14.5 | |
MP-series pumps require the use of an external reservoir. Optional 2 gallon reservoir MP-10T available.
Pump includes .060 in. thick gasket for reservoir mounting.
