B, RA-系@，動力油缸和接收增壓器
防止雜質(zhì)進入液壓缸系統(tǒng)
無滲漏隨行系統(tǒng)消除了連接處漏油的可能
閉式設計可防止加工碎片和冷卻液進入液壓系統(tǒng)
增壓器既可水平安裝也可垂直安裝以增加夾具設計的柔性
|
Pressure Ratio |
Oil Flow Ratio |
Oil Volume per Stroke inch3 |
Stroke inch |
Receiver Booster Model Number |
Activator Wand Model Number |
Effective Area inch2 |
Operating Pressure psi |
Weight lbs |
|---|---|---|---|---|---|---|---|---|
| 2:1 | 1.75:1 | 8.10 | 2.04 | B-81 | – | 3.98 | 400 - 5000 | 12.7 |
| 2:1 | 1.75:1 | 17.10 | 4.30 | B-171 | – | 3.98 | 400 - 5000 | 15.7 |
| – | – | 9.90 | 4.44 | – | RA-1061 | 2.23 | 800 - 10,000 | 11.3 |
