CA, MA-系列@夾緊臂 用于擺動油缸
專利設計
在任意位置夾緊臂均可方便精確地定位
油缸安裝在夾具面上后夾緊臂也可方便而精確地安裝與固定
無需用夾鉗緊固夾緊臂
壓力與夾緊力的曲線圖
選用不同長度的夾緊臂要求相應的油壓會導致不同的夾緊力
壓力 vs. clamping force
The use of different 長度 clamp arms requires reduction in applied hydraulic 壓力 and resulting clamp force. Download the catalogue page showing the diagrams showing the 壓力 versus clamping force
|
Clamp Arm Length |
Clamping Force |
For Swing Cylinders |
For Collet-Lok® |
Clamp Arm Model Number |
|
|---|---|---|---|---|---|
|
SU, SL-Series ST, SC Series |
WPFL/R-series WPTL/R-series |
||||
| inch | pound |
Standard Arm |
Long Arm |
||
| 1.60 | 500 | 21, 22 | – | CAS-21 | – |
| 2.39 | 1250 | 51, 52 | – | CAS-51 | – |
| 2.99 | 2025 | 92 | – | CAS-92 | – |
| 3.13 | 2600 | 121, 122 | – | CAS-121 | – |
| 3.72 | 4200 | 201 | – | CAS-201 | – |
| 4.65 | 7600 | 351 | – | CAS-351 | – |
| 3.63 | 500 | 21, 22 | – | – | CAL-22 |
| 5.81 | 1250 | 51, 52 | – | – | CAL-52 |
| 7.09 | 2025 | 92 | – | – | CAL-92 |
| 7.06 | 2600 | 121, 122 | – | – | CAL-122 |
| 7.95 | 4200 | 201 | – | – | CAL-202 |
| 8.47 | 7600 | 351 | – | – | CAL-352 |
